Specifications
| Reference | Ø 1 (mm) | DN 1 | Thickness (mm) | Material |
|---|---|---|---|---|
| ITM41025 | 25.0 | 20 | 1.5 | AISI 304L |
| ITM61025 | 25.0 | 20 | 1.5 | AISI 316L |
| ITM41028 | 28.0 | 20 | 1.5 | AISI 304L |
| ITM61028 | 28.0 | 20 | 1.5 | AISI 316L |
| ITM41033 | 33.0 | 25 | 1.5 | AISI 304L |
| ITM61033 | 33.0 | 25 | 1.5 | AISI 316L |
| ITM41043 | 43.0 | 40 | 1.5 | AISI 304L |
| ITM61043 | 43.0 | 40 | 1.5 | AISI 316L |
| ITM41050 | 50.8 | 50 | 1.5 | AISI 304L |
| ITM61050 | 50.8 | 50 | 1.5 | AISI 316L |
| ITM41053 | 53.0 | 50 | 1.5 | AISI 304L |
| ITM61053 | 53.0 | 50 | 1.5 | AISI 316L |
| ITM41063 | 63.5 | 50 | 1.5 | AISI 304L |
| ITM61063 | 63.5 | 50 | 1.5 | AISI 316L |
| ITM41073 | 73.0 | 65 | 1.5 | AISI 304L |
| ITM61073 | 73.0 | 65 | 1.5 | AISI 316L |
| ITM42084 | 84.0 | 80 | 2 | AISI 304L |
| ITM62084 | 84.0 | 80 | 2 | AISI 316L |
| ITM42104 | 104.0 | 100 | 2 | AISI 304L |
| ITM62104 | 104.0 | 100 | 2 | AISI 316L |
| ITM42129 | 129.0 | 125 | 2 | AISI 304L |
| ITM62129 | 129.0 | 125 | 2 | AISI 316L |
| ITM42154 | 154.0 | 150 | 2 | AISI 304L |
| ITM62154 | 154.0 | 150 | 2 | AISI 316L |
| ITM42204 | 204.0 | 200 | 2 | AISI 304L |
| ITM62204 | 204.0 | 200 | 2 | AISI 316L |
| ITM42254 | 254.0 | 250 | 2 | AISI 304L |
| ITM62254 | 254.0 | 250 | 2 | AISI 316L |
| ITM62304 | 304.0 | 300 | 2 | AISI 316L |
| ITM62354 | 354.0 | 300 | 2 | AISI 316L |
Technical documentation
Note: due to the constant development of our products, the supplied data can be altered without prior notice.
| Document | Type | Language | File size |
|---|---|---|---|
| FT TI INOX AISI 304L MILIMÉTRICO.pdf | Data Sheet | IT | 371,07 KB |
| FT TÊ INOX AISI 304L MILIMÉTRICO.pdf | Data Sheet | PT | 372,58 KB |
| FT TE INOX AISI 304L MILIMÉTRICO.pdf | Data Sheet | ES | 371,13 KB |
| Data Sheet | FR | 371,13 KB | |
| Data Sheet | EN | 371,13 KB | |
| Data Sheet | FR | 369,08 KB | |
| FT TÊ INOX AISI 316L MILIMÉTRICO.pdf | Data Sheet | PT | 370,17 KB |
| FT TE INOX AISI 316L MILIMÉTRICO.pdf | Data Sheet | ES | 369,08 KB |
| Data Sheet | EN | 369,08 KB | |
| FT TI INOX AISI 316L MILIMÉTRICO.pdf | Data Sheet | IT | 368,63 KB |
| IMAGE HQ SSF-ITM.jpg | HQ Image | 2,43 MB |
