Customer castings pages
Malleable cast iron foundry
ATUSA has more than 75 years experience in the manufacture of malleable cast iron parts for the most competitive markets, offering customized solutions according to the drawings and specifications of each client.
Its great versatility in the production of various materials, qualities and finishes, the flexibility of its facilities and the expertise of its staff, give it the knowledge necessary to advise its clients on the development of customized solutions.
The prestige acquired through its long history has made ATUSA a qualified manufacturer thanks to its engineering, quality and service. The demanding sectors at which its industrial products are aimed and the loyalty of its customers consolidate ATUSA as a reference supplier.
Applications
For castings and / or assemblies, ATUSA is the best option for its clients, who are leaders in the following sectors:
- Electrical industry
- Construction industry, infrastructure and public works
- Automotive industry
- Chemical industry
- Hand tool industry
- Farming industry
- Industrial supplies industry
Worldwide presence. ATUSA manufactures in Europe and supplies its customers globally, both in Europe and the rest of the world. As customers of ATUSA are leaders of these industries, the parts manufactured by ATUSA can be found all over the world.
Mechanical Properties of White Heart Malleable Cast Irons
| Material designation | Nominal diameter of test piece d mm | Tensile Strength minimum Rm MPa | Elongation % | 0,2 % Proof Strength minimum Rp0,2 MPa | Brinell hardness maximum ** HBW |
|---|---|---|---|---|---|
| EN-GJMW-360-12* | 12 | 360 | 12 | 190 | 200 |
| EN-GJMW-400-5 | 12 | 400 | 5 | 220 | 220 |
| EN-GJMW-450-7 | 12 | 450 | 7 | 260 | 220 |
| EN-GJMW-550-4 | 12 | 550 | 4 | 340 | 250 |
* Material most suitable for welding
Mechanical Properties of Black Heart Malleable Cast Irons
| Material designation | Nominal diameter of test piece d mm | Tensile Strength minimum Rm MPa | Elongation % | 0,2 % Proof Strength minimum Rp0,2 MPa | Brinell hardness maximum ** HBW |
|---|---|---|---|---|---|
| EN-GJMB-350-10 | 12-15 | 350 | 10 | 200 | 150 |
| EN-GJMB-450-6 | 12-15 | 450 | 6 | 270 | 200 |
| EN-GJMB-550-4 | 12-15 | 550 | 4 | 340 | 230 |
| EN-GJMB-650-2 | 12-15 | 650 | 2 | 430 | 260 |
** Only for information
Materials
EN 1562-GJMW (white malleable)
Suitable for small wall thicknesses. Ideal for hot dip galvanizing. Excellent performance for welding (GJMW 360-12)
EN 1562-GJMB (black malleable)
Suitable for large wall thicknesses
Easy machining chip removal
Homogeneous metallographic structure
Engineering
Extensive experience in the manufacture of malleable cast iron provides ATUSA with the necessary knowledge to advise the client, from the beginning of the process, in the development of customized solutions, co-designing the parts in close collaboration with the client in order to optimize them in the most complicated and demanding applications, thus satisfying the needs of each client.
Through its qualified staff and technical tools, such as the latest software in the field of calculations and filling simulation, or in the manufacture of utilities and tools for subsequent processes and operations, the test samples and pre-series are designed, manufactured and tested until the optimum result for mass production is achieved.
Productive means
ATUSA has 3 manufacturing plants employing more than 1,000 people in 8 countries, its production capacity is close to 25,000 tons per year. This, together with its wide distribution network, allow it to be a priority supplier in more than 40 countries throughout the world.
In addition to maintaining exceptional quality standards, its modern facilities provide ATUSA with great capacity and flexibility in the production of castings; from 0.1kg to 30 kgs and up to Ø400mm x 130mm in height.
For its manufacturing processes, ATUSA has:
- Tool manufacturing workshops
- Induction melting furnaces
- Automatic molding in vertical and horizontal lines
- Hot and cold process core boxes
- Heat treatment furnaces
- Automatic hot-dip galvanizing lines, both static and dynamic
- Machining park and control machines
- Robot park for roughing, deburring and online control operations
Quality
ATUSA manufactures according to the ISO 9001: 2015 standard Quality assurance. Accordingly, it can offer an optimal quality service, providing its customers with added value while maintaining the aim of achieving excellence in its activity through its policy of continuous improvement. To verify the quality of its products, ATUSA has the most modern and efficient technical means and analysis procedures at the disposal of its experienced staff, who oversee the correct performance of the Quality System, being able to carry out on-site tests of:
- Chemical analysis
- Magnetic / penetrant liquid controls
- Traction
- Three-dimensional measurement
- Metallographic analysis
- X-rays
And issue the corresponding certificates required by the applicable standards, carry out specific product approvals and all the particular tests requested by customers, resorting, if necessary, to the support of impartial verification entities or external laboratories.
Certifications
