Specifications
| Reference | Ø 1 (mm) | DN 1 | Thickness (mm) | Material |
|---|---|---|---|---|
| ICM41025 | 25.0 | 20 | 1.5 | AISI 304L |
| ICM61025 | 25.0 | 20 | 1.5 | AISI 316L |
| ICM41028 | 28.0 | 20 | 1.5 | AISI 304L |
| ICM61028 | 28.0 | 20 | 1.5 | AISI 316L |
| ICM41033 | 33.0 | 25 | 1.5 | AISI 304L |
| ICM61033 | 33.0 | 25 | 1.5 | AISI 316L |
| ICM41043 | 43.0 | 40 | 1.5 | AISI 304L |
| ICM61043 | 43.0 | 40 | 1.5 | AISI 316L |
| ICM41050 | 50.8 | 50 | 1.5 | AISI 304L |
| ICM61050 | 50.8 | 50 | 1.5 | AISI 316L |
| ICM41053 | 53.0 | 50 | 1.5 | AISI 304L |
| ICM61053 | 53.0 | 50 | 1.5 | AISI 316L |
| ICM41063 | 63.5 | 50 | 1.5 | AISI 304L |
| ICM61063 | 63.5 | 50 | 1.5 | AISI 316L |
| ICM41073 | 73.0 | 65 | 1.5 | AISI 304L |
| ICM61073 | 73.0 | 65 | 1.5 | AISI 316L |
| ICM42070 | 70.0 | 65 | 2 | AISI 304L |
| ICM62070 | 70.0 | 65 | 2 | AISI 316L |
| ICM42084 | 84.0 | 80 | 2 | AISI 304L |
| ICM62084 | 84.0 | 80 | 2 | AISI 316L |
| ICM42104 | 104.0 | 100 | 2 | AISI 304L |
| ICM62104 | 104.0 | 100 | 2 | AISI 316L |
| ICM42129 | 129.0 | 125 | 2 | AISI 304L |
| ICM62129 | 129.0 | 125 | 2 | AISI 316L |
| ICM42154 | 154.0 | 150 | 2 | AISI 304L |
| ICM62154 | 154.0 | 150 | 2 | AISI 316L |
| ICM42204 | 204.0 | 200 | 2 | AISI 304L |
| ICM62204 | 204.0 | 200 | 2 | AISI 316L |
| ICM42254 | 254.0 | 250 | 2 | AISI 304L |
| ICM62254 | 254.0 | 250 | 2 | AISI 316L |
| ICM42304 | 304.0 | 300 | 2 | AISI 304L |
| ICM62304 | 304.0 | 300 | 2 | AISI 316L |
| ICM42354 | 354.0 | 300 | 2 | AISI 304L |
| ICM62354 | 354.0 | 300 | 2 | AISI 316L |
Technical documentation
Note: due to the constant development of our products, the supplied data can be altered without prior notice.
