Specifications
| Reference | Out Ø (mm) | Out Ø (mm) |
|---|---|---|
| WR011063 | 110 | 63 |
| WR011075 | 110 | 75 |
| WR011090 | 110 | 90 |
| WR012590 | 125 | 90 |
| WR016090 | 160 | 90 |
| WR075063 | 75 | 63 |
| WR090063 | 90 | 63 |
| WR090075 | 90 | 75 |
| WR125110 | 125 | 110 |
| WR140110 | 140 | 110 |
| WR140125 | 140 | 125 |
| WR160110 | 160 | 110 |
| WR160125 | 160 | 125 |
| WR160140 | 160 | 140 |
| WR200160 | 200 | 160 |
| WR250160 | 250 | 160 |
| WR250200 | 250 | 200 |
Technical documentation
Note: due to the constant development of our products, the supplied data can be altered without prior notice.
| Document | Type | Language | File size |
|---|---|---|---|
| DS DIN 2573 PN 6 THREADED FLANGE.pdf | Data Sheet | EN | 396,31 KB |
| FT BRIDA ROSCADA DIN 2573 PN 6.pdf | Data Sheet | ES | 396,31 KB |
| FT FLANGE ROSCADA DIN 2573 PN 6.pdf | Data Sheet | PT | 397,09 KB |
| FT FLANGIA FILETTATA DIN 2573 PN 6.pdf | Data Sheet | IT | 395,83 KB |
| FT BRIDES TARAUDÉES DIN 2573 PN 6.pdf | Data Sheet | FR | 398,40 KB |
| IMAGE HQ PEF-WR.jpg | HQ Image | 242,66 KB | |
| TA nº 25 - ACCESORIOS PE PARA SOLDAR A TOPE - INSTRUCCIONES DE MONTAJE.pdf | Technical Articles | EN - ES - PT - FR | 455,37 KB |
| TA nº 25 - ACESSÓRIOS PE PARA SOLDAR TOPO A TOPO - INSTRUÇÕES DE MONTAGEM.pdf | Technical Articles | EN - ES - PT - FR | 455,37 KB |
| TA nº 25 - ACCESSOIRES PE DE SOUDAGE BOUT À BOUT - INSTRUCTIONS DE MONTAGE.pdf | Technical Articles | EN - ES - PT - FR | 455,37 KB |
| TA nº 25 - PE BUTT WELD FITTINGS - ASSEMBLY INSTRUCTIONS.pdf | Technical Articles | EN - ES - PT - FR | 455,37 KB |
