Specifications
| Reference | Inch Ø 1 | Out Ø (mm) |
|---|---|---|
| CXSS9001 | 1" | 33.4 |
| CXSS901C | 1 1/4" | 42.2 |
| CXSS901M | 1 1/2" | 48.3 |
| CXSS9002 | 2" | 60.3 |
| CXSS902M | 2 1/2" | 73.0 |
| CXSS9003 | 3" | 88.9 |
| CXSS9004 | 4" | 114.3 |
| CXSS9005 | 5" | 141.3 |
| CXSS9006 | 6" | 168.3 |
| CXSS9008 | 8" | 219.1 |
| CXSS9010 | 10" | 273.0 |
| CXSS9012 | 12" | 323.8 |
| CXSS9014 | 14" | 355.6 |
| CXSS9016 | 16" | 406.4 |
Technical documentation
Note: due to the constant development of our products, the supplied data can be altered without prior notice.
| Document | Type | Language | File size |
|---|---|---|---|
| DS ASTM STD & XS SHORT RADIUS ELBOW.pdf | Data Sheet | EN | 462,56 KB |
| FT CODO RADIO CORTO 90º ASTM STD & XS.pdf | Data Sheet | ES | 462,56 KB |
| FT COURBE PETIT RAYON 90º ASTM STD & XS.pdf | Data Sheet | FR | 462,93 KB |
| FT CURVE RAGGIO CORTO 90º ASTM STD & XS.pdf | Data Sheet | IT | 462,58 KB |
| FT CURVA RAIO CURTO 90º ASTM STD & XS.pdf | Data Sheet | PT | 463,53 KB |
| IMAGE HQ CF-CSTS.jpg | HQ Image | 1,14 MB |
