Specifications
| Reference | Inch Ø 1 | Out Ø (mm) |
|---|---|---|
| CSTL450M | 1/2" | 21.3 |
| CSTL450T | 3/4" | 26.7 |
| CSTL4501 | 1" | 33.4 |
| CSTL451C | 1 1/4" | 42.2 |
| CSTL451M | 1 1/2" | 48.3 |
| CSTL4502 | 2" | 60.3 |
| CSTL452M | 2 1/2" | 73.0 |
| CSTL4503 | 3" | 88.9 |
| CSTL453M | 3 1/2" | 101.6 |
| CSTL4504 | 4" | 114.3 |
| CSTL4505 | 5" | 141.3 |
| CSTL4506 | 6" | 168.3 |
| CSTL4508 | 8" | 219.1 |
| CSTL4510 | 10" | 273.0 |
| CSTL4512 | 12" | 323.8 |
| CSTL4514 | 14" | 355.6 |
| CSTL4516 | 16" | 406.4 |
| CSTL4518 | 18" | 457.0 |
| CSTL4520 | 20" | 508.0 |
| CSTL4524 | 24" | 610.0 |
Technical documentation
Note: due to the constant development of our products, the supplied data can be altered without prior notice.
| Document | Type | Language | File size |
|---|---|---|---|
| FT CODO RADIO LARGO 45º ASTM STD & XS.pdf | Data Sheet | ES | 495,01 KB |
| FT COURBE GRAND RAYON 45º ASTM STD & XS.pdf | Data Sheet | FR | 495,74 KB |
| DS ASTM STD & XS LONG RADIUS 45º ELBOW.pdf | Data Sheet | EN | 495,01 KB |
| FT CURVA RAIO LONGO 45º ASTM STD & XS.pdf | Data Sheet | PT | 496,57 KB |
| FT CURVE RAGGIO LUNGO 45º ASTM STD & XS.pdf | Data Sheet | IT | 434,05 KB |
| IMAGE HQ CF-CSTL45.jpg | HQ Image | 1,07 MB |
