Specifications
| Reference | Inch Ø 1 | Thickness (mm) | Out Ø (mm) |
|---|---|---|---|
| C3450021 | 1/2" | 2.0 | 21.3 |
| C3450027 | 3/4" | 2.3 | 26.9 |
| C3450033 | 1" | 2.6 | 33.7 |
| C3450042 | 1 1/4" | 2.6 | 42.4 |
| C3450048 | 1 1/2" | 2.6 | 48.3 |
| C3450060 | 2" | 2.9 | 60.3 |
| C3450076 | 2 1/2" | 2.9 | 76.1 |
| C3450089 | 3" | 3.2 | 88.9 |
| C3450101 | 3 1/2" | 3.6 | 101.6 |
| C3450114 | 4" | 3.6 | 114.3 |
| C3450139 | 5" | 4.0 | 139.7 |
| C3450168 | 6" | 4.5 | 168.3 |
| C3450219 | 8" | 6.3 | 219.1 |
| C3450273 | 10" | 6.3 | 273.0 |
| C3450324 | 12" | 7.1 | 323.9 |
| C3450355 | 14" | 8.0 | 355.6 |
| C3450406 | 16" | 8.8 | 406.4 |
Technical documentation
Note: due to the constant development of our products, the supplied data can be altered without prior notice.
| Document | Type | Language | File size |
|---|---|---|---|
| DS EN 10253-2 3D ELBOW 45º.pdf | Data Sheet | EN | 422,96 KB |
| FT CODO 3D 45º EN 10253-2.pdf | Data Sheet | ES | 422,96 KB |
| FT CURVE 3D 45º EN 10253-2.pdf | Data Sheet | IT | 423,04 KB |
| FT COURBES 3D 45º EN 10253-2.pdf | Data Sheet | FR | 424,40 KB |
| FT CURVA 3D 45º EN 10253-2.pdf | Data Sheet | PT | 424,03 KB |
| IMAGE HQ CF-C318.jpg | HQ Image | 801,14 KB | |
| TA nº 12 - ACCESORIOS PARA SOLDAR A TOPE EN 10253-1.pdf | Technical Articles | EN - ES | 2,27 MB |
| TA nº 12 - ACESSÓRIOS PARA SOLDAR TOPO A TOPO EN 10253-1.pdf | Technical Articles | PT | 2,18 MB |
