Specifications
| Reference | Inch Ø 1 | Out Ø (mm) |
|---|---|---|
| CL90460M | 1/2" | 21.3 |
| CL90460T | 3/4" | 26.9 |
| CL904601 | 1" | 33.7 |
| CL90461C | 1 1/4" | 42.4 |
| CL90461M | 1 1/2" | 48.3 |
| CL904602 | 2" | 60.3 |
| CL90462M | 2 1/2" | 73.0 |
| CL904603 | 3" | 88.9 |
| CL904604 | 4" | 114.3 |
| CL904605 | 5" | 141.3 |
| CL904606 | 6" | 168.3 |
| CL904608 | 8" | 219.1 |
| CL904610 | 10" | 273.0 |
Technical documentation
Note: due to the constant development of our products, the supplied data can be altered without prior notice.
| Document | Type | Language | File size |
|---|---|---|---|
| Data Sheet | DE | 389,20 KB | |
| FT COURBE GRAND RAYON 90º ASTM A-420 WPL6 STD.pdf | Data Sheet | FR | 388,84 KB |
| FT CURVA RAIO LONGO 90º ASTM A-420 WPL6 STD.pdf | Data Sheet | PT | 390,08 KB |
| DS ASTM A-420 WPL6 LONG RADIUS ELBOW 90º.pdf | Data Sheet | EN | 389,20 KB |
| FT CODO RADIO LARGO 90º ASTM A-420 WPL6 STD.pdf | Data Sheet | ES | 389,20 KB |
| FT CURVE RAGGIO LUNGO 90º ASTM A-420 WPL6 STD.pdf | Data Sheet | IT | 389,33 KB |
| IMAGE HQ CF-CSTL90.jpg | HQ Image | 1,27 MB |
