Specifications
| Reference | Inch Ø 1 | Ø 1 (mm) | DN 1 | PN | Standard |
|---|---|---|---|---|---|
| FW150015 | 1/2" | 21.3 | 15 | 150 Lbs. | ASTM |
| FW150020 | 3/4" | 26.9 | 20 | 150 Lbs. | ASTM |
| FW150025 | 1" | 33.7 | 25 | 150 Lbs. | ASTM |
| FW150032 | 1 1/4" | 42.4 | 32 | 150 Lbs. | ASTM |
| FW150040 | 1 1/2" | 48.3 | 40 | 150 Lbs. | ASTM |
| FW150050 | 2" | 60.3 | 50 | 150 Lbs. | ASTM |
Technical documentation
Note: due to the constant development of our products, the supplied data can be altered without prior notice.
| Document | Type | Language | File size |
|---|---|---|---|
| DS 150 LBS SOCKET WELDING FLANGE.pdf | Data Sheet | EN | 291,92 KB |
| FT BRIDE SOCKET WELDING 150 LBS.pdf | Data Sheet | FR | 293,15 KB |
| FT BRIDA SOCKET WELDING 150 LBS.pdf | Data Sheet | ES | 291,92 KB |
| FT FLANGE SOCKET WELDING B16.5 150 LBS.pdf | Data Sheet | PT | 293,81 KB |
| FT FLANGE SOCKET WELDING B16.5 150 LBS.pdf | Data Sheet | IT | 292,88 KB |
| IMAGE HQ CF-FW.jpg | HQ Image | 1,58 MB | |
| TA nº 30 - PARAFUSOS EM AÇO - CLASSE DE QUALIDADE - CONCEITO E EXEMPLOS.pdf | Technical Articles | PT | 261,75 KB |
| TA nº 30 - TORNILLOS EN ACERO - CLASE DE CALIDAD - CONCEPTO Y EJEMPLOS.pdf | Technical Articles | ES | 260,37 KB |
| TA nº 30 - VIS EN ACIER – CLASSE DE QUALITE - CONCEPT ET EXEMPLES.pdf | Technical Articles | FR | 261,35 KB |
| TA nº 30 - BULLONI IN ACCIAIO - CLASSI DI RESISTENZA - CONCETTO ED ESEMPI.pdf | Technical Articles | IT | 260,76 KB |
| TA Nº 30 - STEEL BOLTS - PROPERTY CLASS - CONCEPT AND EXAMPLES.pdf | Technical Articles | EN | 260,39 KB |
